This versatile laminating and mounting machine is designed to laminate digital prints, or to mount prints to foam core, gator board or other substrates. Easy-to-operate, this is a reliable and rugged laminator and mounting machine.
Features:
- Silicone rubber rollers
- 2 sets of rollers for flat results
- Roll tension control
- Variable speed
- Independent temperature controls
- Large feed tray
- Swing-away heaters for easy cleaning
Options:
- Roll Feed Assembly for laminating roll to roll
- Release liner takeup for PSA films
- Slitter assembly
Specifications
| Origin: | Made in USA |
| Dimensions: | 53” (L), 26” (H), 34” (D) |
| Speed: | up to 30 feet per minute |
| Warranty: | 2-years, excluding normal wear and tear or abuse |
| Laminating Width: | up to 42” |
| Laminating Length: | unlimited |
| Roller Diameter: | 3” |
| Film Core: | 3” |
| Film Thickness, per side: | up to 10 mil |
| Electrical: | 208 - 240V, single phase, 50/60 Hz, 30 amps |
| Certification: | Standard |
| Weight / Shipping weight: | 480/800 lbs |
